Low Voltage Dry Tpye Series Reactor
Product introduction：
Using high quality silicon steel sheet and high strength wire processed , with low inflaming retarding and loss , moisture- proof , small noise , low temperature rise.
Each reactor with a set of normally closed temperature control switch ( 90℃ ) , Series in the control loop, When the reactor is over temperature Control circuit automatic disconnection, Let the entire set of compensation loop exit , it have overpower protection function.
| Technical parameters： | |
|---|---|
| Insulation grade: | ≤H level (180℃) |
| Dielectric Strength: | 4KV ground and altemate, time1M, No breakdown |
| Nosie: | ≤48dB ( Test range reactor 1m ) |
| Installation elevation: | under 2000 meters |
| Running temperature: | surrounding temperature -25℃~+45℃ (To ensure good ventilation around ) |
| Spacing distance: | horizontal direction>6CM，vertical direction>12CM |
| Reactance ratio: | 6%、7%、13%、14%、etc，and custom |
| Based on standard: | GB/1094.6- 2011 |
